Aluminized Steel Chain Link Wire Fence

Aluminized steel or aluminum powder coated chain link fence is an option with less cost in commercial uses. It also has the aluminum shine surface to enjoy almost all the features of the real Aluminum fences.

The base metal for making aluminized chain link mesh is composed of commercial quality medium-carbon aluminum coated wire. The wire is coated with aluminum to produce a smooth and uniform coating. The weight of aluminum coating, wire sizes with allowable variances, and wire breaking strength, conform to ASTM A 817 for the wire size specified. The wire is aluminum coated before weaving.

The coating is produced by passing the cleaned wire through a melting bath of aluminum metal.

Aluminum coated steel chain link fence offer the following features: Corrosion resistance, Lightness and nice appearance, Long life time, High tensile and easy installation, Adapt to the harsh environment.Standards:
ASTM A 491 Aluminum-Coated Steel Chain Link Fence.
ASTM F567 Installation of Chain Mesh Fencing.
ASTM A 817 Metallic-Coated Wire for use in Chain-Link Fence Federal specification. RR-F- 191 K/1 D Type II, Fencing, Wire and Post Metal (Chain-Link Fence Fabric) American Association of State Highway Transportation Officials M-181 Chain Link Mesh, Type II.

Specifications:
Aluminized fabric is available in mesh sizes from 3/8 inch to 2 inches, and in heights from 36 inches to 240 inches. Unless otherwise specified, chain link fabric woven with a 2 inch (50 mm) mesh and 60 inches (1,520 mm) or less in height is knuckled at both selvages;
Chain link fence end types: K- Knuckle, B- Barb.

Aluminum Chain Link Fencing Applications:
Aluminum coated (aluminized) steel chain link for commercial, industrial and institutional applications. Aluminized fabric is contained in various government specifications for use in prison, road, dock, airport, housing, forestry, and military use

Aluminized Steel Chain Link Fence-AF05	Aluminized Steel Chain Link Fence-AF06

Aluminum chain link fencing using with barbed wire

Here is the chain link fence, barbed wire, other accessories specification needed.Standard 50 x 10 gauge (mesh x gauge) Aluminum chain link Mesh (3M high x 2600M Length) (3.1 - 3.24mm diameter).Strands of Aluminum Barded Wire (2.2mm diameter).Strands of 3.25 mm straining wire (4.0 - 5.5mm diameter).25 x 4 mm galvanized steel metal beading.65mm x 65mm x 6mm galvanized steel angle.Straight barbed wire: 2.5mm diameter.Barbed wire spring (for making wire barbs) : 2.2mm diameter.Line straining wire (straight wire): 4.0 - 5.5mm diameter.Chain link for mesh: 3.1 - 3.24mm diameter.aluminum alloy is Al Mg 2.5 or equivalent.

Strength of the materials:
