 |  | | Razor Barbed Wire-01 | Razor Barbed Wire-02 |
Anping Innaer wire mesh Co,.Ltd produce Single coil razor wire, cross type razor wire, concertina razor wire, razor wire barrier, flat wrap razor wire. Packing: packed in waterproof paper and outside woven cloth, We can also produce it as per customers' requirements. Applications:mainly used in industry, agriculture, grass boundary, railway, highway security. Razor Blade Specification:
Concertina Barbed Tape (CBT): Barbed Tape Obstacle (BTO)  |  | | Razor Barbed Wire-03 | Razor Barbed Wire-04 |  |  | | Razor Barbed Wire-05 | Razor Barbed Wire-06 |
Barbed Tape Wire Specification: Razor Blade Specification | Reference Number | Blade Style | Thickness | Wire Dia | Barb
Length | Barb
Width | Barb
spacing | BTO-10 |
| 0.5±0.05 | 2.5±0.1 | 12±1 | 13±1 | 26±1 | BTO-12 |
| 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 | BTO-18 |
| 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 | BTO-22 |
| 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 | BTO-28 |
| 0.5±0.05 | 2.5±0.1 | 28±1 | 15±1 | 34±1 | BTO-30 |
| 0.5±0.05 | 2.5±0.1 | 30±1 | 18±1 | 34±1 | CBT-60 |
| 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 96±2 | CBT-65 |
| 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 | RAZOR WIRE SPECIFICATION | COIL OD | LOOPS/ COIL | TOTAL LENGTH | SIZE | TYPE | 450mm | 33 | 7-8M | CBT-60.65 | Single coil | 500mm | 56 | 12-13M | CBT-60.65 | Single coil | 700mm | 56 | 13-14M | CBT-60.65 | Single coil | 960mm | 56 | 14-15M | CBT-60.65 | Single coil | 450mm | 56 | 8-9M (3 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 500mm | 56 | 9-10M (3 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 600mm | 56 | 10-11M (3 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 600mm | 56 | 8-10M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 700mm | 56 | 10-12M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 800mm | 56 | 11-13M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 900mm | 56 | 12-14M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 960mm | 56 | 13-15M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | 980mm | 56 | 14-16M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type | More products please see Anping County Innaer Wire Mesh Manufacturing Co,.Ltd  |  | | Razor Barbed Wire-07 | Razor Barbed Wire-08 |
|
